ICS 2
Compact Speaker for Installation
Passive 2-way loudspeaker with d’Appolito design in an discreet mini size format, which is equally suitable for speech or music reproduction at moderate signal levels with its linear frequency response.
Where To Buyadd to quote request
Application
- designed for horizontal as well as for vertical mounting
- background sound (gastronomy, conference rooms, museums, theatres)
- near fills
- spatial sound
Sound
- smooth and balanced reproduction of the high frequencies
- low acoustic feedback behaviour
- natural and transparent sound
Optional features
- 100V transformer for ELA systems
- optional RAL-colour available
- increased moisture resistance
- connector panel for fixed connection
Specifications
| Components | 2x 4" + 1x 1" dome tweeter |
|---|---|
| Dispersion (h x v) | 80° x 40° |
| Nominal load (AES / program) | 125 / 250 W |
| Impedance | 16 ohms |
| SPL nom. (Fullspace@1W/1m) / max. SPL (at AES nominal load) | 88 / 112 dB |
| Frequency range (-10 dB) | 120 Hz - 20 kHz |
| Dimensions (W x H x D) | 135 x 290 x 166 mm |
| Weight | 3,5 kg |
| Connectors | 2x Neutrik Speakon NL4 + 2x Phoenix (In/Out) |
| Finishing | PU coating |
| Protective grille | sturdy front grille with acoustic foam |
| Protection class | IP44 |
| Certification | ballproof according to DIN 18032-3 |
In use / reference projects
This product is used in these reference projects:
compatible system amplifier
Digital Amplifier DA 428
The DA 428 is a fully digital multi-channel power amplifier with extensive audio DSP functionality and four Class D power amplifiers of the latest generation. Practical operating gestures make the handling of even complex functions very easy, such as the preset settings on the device.
Fisco | ICS 2 compatible products and accessories
Subwoofer for Installation IB 8
Passive 8“ bassreflex subwoofer in ultra compact wegde design for wall, ceiling and egde mount with a deep bass reproduction.
Accessory Installation | ICS U-bracket
U-bracket for easy mounting of ICS 2 on a wall.
The bracket can be mounted upright or crosswise.
Accessory Installation | ICS Flying Frame
Flying Frame for mounting ICS 2 or ICS 4.
Accessory Installation | ICS Multimount Mini
Extremely compact wall mount for ICS 1 or ICS 2 which is attached to the top or bottom of the speaker. The lockable cardan joint guarantees easy and permanent alignment in two axes.
Accessory Installation | 100 V Transformer 100 V Transformer
100 V Transformer for ICS 2 and ICS 4.
The transformer has an excellent efficiency, the frequency range is between 50 Hz in the low range and up to 18,000 Hz in the high range.
